Product Description
FOCUSUN FIB series of block ice machine is a new type with high
efficiency units, which mainly aiming at the Africa, Middle East
and Oceania. This block ice machine units adopt the integrated
design, easy to install, just need connect the power.
The introduction of ice block machine is very important for
customers. Pls contact us with details to know and better
understand. Here we explain the details in brief:
1. Daily production capacity: The output of our ice block maker is
from 1ton per day to 100tons per day. But if export to abroad, we
suggest make several units to reach capacity for direct technology
block ice machine due to the limitation of transportation.
2. Weight of ice block: The weight of the smallest block ice is 5kg
and this size is at most for daily capacity 5tons, that's because
if we make a more than 5tons daily production ice block machine,
the cost will increase and evaporator too big not easy for
shipment.
3. Ice freezing time: For 5kg, 10kg, 15kg, the ice freezing time is
5.5 hours. For 20kg, 25kg, the ice freezing time is 7.5hours, For
50kg, the ice freezing time will be 8hours to 12hours.
PICTURES OF EVAPORATOR INSIDE, ICE FREEZING INSIDE EVAPORATOR
Focusun Block Ice Machine - Customized ice machinery and
one-station solution (Turnkey solution)
Features of ice block machine:
1.The evaporator adopts special aluminium alloy plate which is more
durable and reaches food hygiene requirements.
2. Ice thawing and ice doffing are fully automatic. No manual work is needed and the process is
time-saving thus more efficient.
3. The ice is doffed by batch and the whole ice-doffing process
only takes 25 minutes.
4. The whole batch of ice blocks can be moved by forklift. Quick
and convenient.
5. Module design makes the ice maker easy to transport, move and
install.
6. Every direct refrigeration block ice machine can be designed and
produced according to your specific requirements.
7. The direct refrigeration block ice maker machine can be
installed in 20ft or 40ft brand new container with other relevant
equipments.
8. Bitzer refrigeration system to guarantee performance;
9. Good heat isulation for water tank;
10. Focusun block ice machine is Good appearance,easy opeartion and
maintenance.
11. Machine can be made into containerized model
PICTURES OF THE WHOLE BLOCK ICE MAKING PLANT, ICE DOFFING ON THE
ICE RECEIVING PLATE DIRECTLY
Company Information
WHY CHOOSE FOCUSUN?
For each type of BLOCK ice machine, different models and customized
design can meet every specific demand. The capacity of ice block
machines ranges from 0.5ton per day to more than 100 ton per day. Here at Focusun, we set no limit to our competence.
At Focusun, we strive to offer high quality manufacturing in the
most cost efficient way. We are environmentally conscious and
provide green technology with high energy efficiency for a cleaner
environment. We have kept improving the manufacturing and design of
ice making machines. We have earned our position as a reliable
supplier in our long diverse portifolio of global customers,
through consistency and efficiency in the quality of our products
and services.
Ice discharged, take block ice out to ice storage. This is standard
design.
If you want special design, we could add ice moving out devide,
when the ice doffed, through this ice moving devide, more easy to
move ice out to ice storage. But cost is higher
Advantages of Focusun:
1. Leading ice making machines manufacturer with rich experience;
2. One-station solution for ice storage room ,cold room, packing
sytsem, ice delivery system, etc.
3. Adopt famous high quality components to guarantee the quality;
4. Many successful cases like
Location | Project Owner | Focusun Products | Time |
Germany | NOVOFERM INC. | Water Chiller+Block Ice Maker+Ice Storage Room | Jul.2009 |
Oman | FIVE OCEAN GROUP | Big Capacity Block Ice Storage and Related Equipments | Aug.2011 |
South Africa | SASOL SOUTH AFRICA | Block Ice Maker Machine+Water Chiller | Nov.2009 |
Germany | BOSCH | Block Ice Maker System | Mar.2010 |
India | FALSON ICE | Movable Ice Plant | Oct.2012 |
Saudi Arabia | FLOWER ICE COMPANY | Evaporative Cooling Big Capacity Block Ice Plant | May.2012 |
Congo | ACE IMPORT AND EXPORT Ltd | Direct Refrigeration Block Ice Plant | Feb.2010 |
Iraq | BAKARR CORPORATION | Brine Big Capacity Ice Plant | Jan.2009 |
Philippines | WESSL GENERALl TRAIDING | Ammonia System Block Ice Maker | Sep.2009 |
Australia | ENGINEERING CONSTRUCTION COMPANY | Direct Refrigeration Block Ice Maker Machine | Dec.2010 |
…… | …… | …… | …… |
5.Professional team for solution design, production, installment
and after-sale service.
Further, if you have no factory, you could consider containerized
block ice machine all equipments installed inside a 20ft or 40ft
container. People operate inside container. Below are 2 different
design with ice moving out device and without ice moving out devide
for india and Sudan customer
Installation:
1). Installing by the user: we will test and install the machine
before shipment, all necessary spare parts, operation manual are
provided to guide the installation.
2).Installing by FOCUSUN engineers:
- (1) We can send our engineer to assist the installation and provide
technical support and train your workers. The end-user should
provide accommodation and round-trip ticket for our engineer.
- (2) Before our engineers’ arrival, the installation place,
electricity, water and installation tools should be prepared.
Meanwhile, we will provide you a Tool List with the machine when
delivery.
- (3) All spare parts are provided according to our standard.
- (4) 2~ 3 workers are required to assist the installation for big
project.
- (5) Any delay due to customer’s reason, USD100/day for one person
as installation fee. Free of charge for one week.
If you are considering to purchase an block ice machine, or you are
just want to know information about the block ice machine and
prepare your business for future, please feel free to contact
Focusun sales team.
To let customer have better understanding, our Focusun company
launched a new website and totally explains the different block ice
machines. Can you visit here : http://www.block-ice-plant.com
Pictures of small block ice machine:
Other products:
Ice Storage:
Ice Crusher:
Ice compactor:
Containerized ice storage movable ice storage
Direct refrigeration block ice machine technical parameter
| Model | Capacity | Refrigerant | Electricity consumption | Installment power | Operating weight | Dimension |
|---|
| -- | Ton/D | -- | Kw | Kw | Kg | mm |
| FIB-05D | 0.5 | R22/R404A | 2.055 | 2.5 | 560 | 1500×800×1800 |
| FIB-10D | 1.0 | R22/R404A | 4.850 | 6.0 | 960 | 1800×1200×2000 |
| FIB-15D | 1.5 | R22/R404A | 6.940 | 8.5 | 1260 | 2800×1200×2000 |
| FIB-20D | 2.0 | R22/R404A | 8.160 | 10.0 | 1460 | 2800×1400×2000 |
| FIB-25D | 2.5 | R22/R404A | 9.510 | 12.0 | 1660 | 3200×1400×2000 |
| FIB-30D | 3.0 | R22/R404A | 11.520 | 14.0 | 2180 | 3600×1400×2200 |
| FIB-35D | 3.5 | R22/R404A | 14.850 | 18.0 | 2100 | 3600×1650×2000 |
| FIB-50D | 5.0 | R22/R404A | 20.900 | 25.0 | Unit:960 | L1400×W1000×H1250 |
| Evaporator:2860 | L4800×W1000×H2250 |
| Cooling tower:670 | 1380×H2170 |
| FIB-100D | 10.0 | R22/R404A | 33.980 | 50.0 | Unit:1680 | L1800×W1000×H1450 |
| Evaporator:2860×2 | L4800×W1000×H2250 |
| Cooling tower:670 | 2000×H2410 |
| FIB-150D | 15.0 | R22/R404A | 59.150 | 75.0 | Unit:2160 | L2000×W1200×H1600 |
| Evaporator:2860×3 | L4800×W1000×H2250 |
| Cooling tower:1120 | 2175×H2565 |
| FIB-200D | 20.0 | R22/R404A | 85.550 | 105.0 | Unit:2896 | L2400×W1600×H1800 |
| Evaporator:2860×4 | L4800×W1000×H2250 |
| Cooling tower:1300 | 2650×H2645 |
| FIB-250D | 25.0 | R22/R404A | 94.050 | 120.0 | Unit:3260 | L3200×W1800×H2200 |
| Evaporator:2860×5 | L4800×W1000×H2250 |
| Cooling tower:1630 | 3050×H2780 |
| FIB-300D | 30.0 | R22/R404A | 113.550 | 150.0 | Unit:3500 | L3000×W2000×H2200 |
| Evaporator:2860×6 | L4800×W1000×H2250 |
| Cooling tower:2730 | 3300×H2785 |
| Standard condition: Dry ball temperature is 33 ℃ and water inlet
temperature is 20℃. |
Also other products:
Focusun flake ice plant series: http://www.flake-ice-plant.com/
Focusun tube ice plant series: http://www.tube-ice-plant.com/
Focusun block ice plant series: http://www.block-ice-plant.com/
We are very interested to have your inquiry.
We are looking forward to give our best supports.
We are also welcome your visit to FOCUSUN CHINA FACTORY to have
face-to-face meeting with our engineering team.
Pls contact me on Whatsapp or wechat +86 15821912409 if you wish
Tell us what daily capacity do you need? Which country do you use
it?
