    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial

    Ask Lasest Price
    Brand Name : FOCUSUN
    Supply Ability : 300 Unit/Units per Year
    Price : $115,000.00/units 1-2 units
    • Product Details
    • Company Profile

    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial

    About Focusun

    Focusun headquarter is located in Shanghai city, production and R&D team is located in Taizhou city, Jiangsu province, with more than 35,000 square meters of standardized modern plant. Our main products include all kinds of ice plant, such as block ice plant, tube ice plant, flake ice plant, cube ice plant, plate ice plant.

    There must be one product suits your business!

    Professional sales teams combined with excellent working experience production. Bring products from factory directly to you, cost of different marketing channels saving.

    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    Product Description

    FOCUSUN continues to provide brine system block ice machine with improved technology, largly improving the ice making efficiency. Put ice cans with full water in the brine tank, through heat exchange, the water in the ice cans all become ice. The crane will hoist a row of cans down into the ice thawing tank full of running warm water. So the ice surface thaws and gets separate from the ice can.

    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial

    Features


    1.Patented UNI-EVEPTM processing technology ensures larger evaporation area and higher cooling efficiency

    2.The part inside brine tank that touches brine water is made of SUS 304 which bears low temperature and highly resists rusts.

    3.Particular can dumper and thawing tank design makes easier operation.

    4.Thawing tank is heated by air discharged from compressor to save much energy and suits for low water temperature area.

    5.Every brine block ice machine can be designed and built as per your specific requirements.

    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    MODE
    DAILY PRODUCTION
    REFRIGERANT
    ELECTRICITY POWER
    SIZE(L*W*H)
    FIB-300ES
    30 TON
    R404A
    112kw
    18000*4000*5000mm
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    Detailed Images
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    SETTING INFORMATION
    Ice Making Theory
    Brine System
    Power Supply
    380V/220V
    Material
    stainless steel 304 and Galvanized steel
    Paiting
    Blue
    Ice Size
    5kg, 10kg, 15kg, 20kg, 25kg, 50kg
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial

    Brine system block ice machine configuration

    1) Brine tank
    The stainless steel part between the brine water and the brine tank highly resists rust and it works well in a cold condition.Concrete brine tank is also suggestibale for some projects.
    2) Ice bucket
    Stainlessw steel 304 and galvanized steel are available.The later is chosen for cost-saving.
    3) Evaporator:
    Paktong tubes are used as evaporator coil to improve the heat transfer effect,and its stainlessness,anti-corrosion can guarantee the long service time.
    4) Agitator:
    Adjust the salt concentration to improve the heat exchange effect.
    5) Can dumper:
    Excellent design guarantees the ice-thawing efficiency.
    6) Thawing tank:
    Heated by hot gas discharged from the compressor so that it is more energy saving and suitable for low water temperature area.

    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    Ice weight:
    5kg (125mm x 100mm x 600mm)

    10kg (155mm x 100mm x 750mm)

    15kg (185mm x 100mm x 750mm)

    20kg (245mm x 125mm x 750mm)

    25kg (315mm x 125mm x 750mm)

    50kg (480mm x 160mm x 750mm)
    Ice-making hours
    5kg 4~4.5hours
    10kg 4~4.5hours
    15kg 4~4.5hours
    20kg 6~6.5hours
    25kg 6~6.5hours
    50kg 9~9.5hours
    Usage
    For seafood, for fishery, all product needs a cooling effect
    Certifications
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    Our Service
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial
    30 Ton Brine Cooling System Ice Block Ice Making Machine For Industrial

    Pre-Sales Service

    * Inquiry and consulting support.

    * View our Factory.

    After-Sales Service

    * Training how to instal the machine, training how to use the machine.

    * Engineers available to service machinery overseas.
