FOCUSUN---Cooling Technical Master Since 1929, Germany

Focusun is a pioneer in ice cooling techlonogy and manufacture worldwide. We mainly design and manufacture tube ice machine, block ice machine, flake ice machine, cube ice machine, plate ice machine, water chiller, concrete cooling system, automatic ice storage system, dynamic ice storage system and all kinds of cold rooms. Over a decade, we have provided quality service to more than 16,000 professional clients in 150 countries around the world. Now we have a factory of 36,000 square meter in Taizhou, Jiangsu province, China.

Focusun (shanghai) Refrigeration Equipment is founded in 2008. In fact, our activity in refrigeration technology is dated back to 2002. In 2012. Focusun(Shanghai) is authorized by Kulinder Incorporation(Germany) to deal with all business, D&M and promotion in China and granted the full right to use the brand of Kulinder, Focusun, pictures and the copyright of design &manufacture in China.

Our tube ice machine is both used in customer consuming and cooling systems, and it's also widely used in restaurants, fast-food stores, supermarkets, healthcare centers, schools, Night clubs & bars, meat plants etc.
This tube ice machine is environmentally safe, using Freon refrigerant. All surfaces that contact with water (including the cover) are stainless steel.

Subject Unit Technical parameter
Power supply Voltage/Phase/Frequency 380V/3P/50Hz

Refrigerant R404A

Capacity Kg/day 2ton

Temperature Ambient temperature ℃ 35

Water inlet temperature ℃ 20

Operating power Total running power Kw 16.03

Installment power Kw 20

Operating power of cutter Kw 0.37

Operating power of cold water pump Kw 0.55

Compressor Manufacturer Bitzer

Refrigeration capacity Kw 36.4

Operating power Kw 13.51

Compressor COP/EER Kw/kw 2.7

Horse power Hp 25

Condenser Fan power Kw 1.6

Cooling way Air cooling

Dimension Size of ice maker (L×W×H)(mm) 1700×1200×2200

Weight of unit Operating weight of tube ice maker Kg 1460

Salient Features of Big Capacity Tube Ice Machine:

- Capacities offered: 1, 000Kgs/24H to 60, 000Kgs/24H.

- Simple design/engineering.

- No requirements of skilled workers.

- High durability, minimal maintenance.

- High energy efficiency.

- SS304 stainless steel tube ice machine

- Water Distributors: Made up of elastic material which creates a continuous and uninterrupted peripheral seal between the tube ends and water distributor.

- Refrigerant: R22/R404a

- Freezer: High quality stainless steel for all water and ice contacting surfaces which are corrosion resistant and easy to clean.

- Cutter: Stainless steel cutters driven by gear motors are uniquely designed to produce both cylindrical and crushed ice simply by reversing the motor of cutter and using a switch on the control panel that controls this function.

- Cutter Motors: Built with heavy duty design to give years of reliable ice-cutting service

- Pumping Tank (Water Pumps): Centrifugal casting iron pump is large enough to circulate the quantity of water to be frozen for many times and produce crystal clear ice.

- Control Panel: Access to the automatically electrical system which performs sequences of freezing and thawing precisely and dependably year after year.

91.8% Response Rate

91.8% Response Rate

91.8% Response Rate

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Also other products:
Focusun flake ice plant series: http://www.flake-ice-plant.com/
Focusun tube ice plant series: http://www.tube-ice-plant.com/
Focusun block ice plant series: http://www.block-ice-plant.com/
If you are considering to purchase an block ice machine, or you are just want to know information about the block ice machine and prepare your business for future, please feel free to contact Focusun sales team.

To make customer have better understanding, our Focusun company launched a new website and totally explains the different block ice machines. Can you visit here : http://www.block-ice-plant.com


We are very interested to have your inquiry.
We are looking forward to give our best supports.
We are also welcome your visit to FOCUSUN CHINA FACTORY to have face-to-face meeting with our engineering team.

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
