Weight(kg/block) Dimension(L*W*H mm) Ice Making Time(Hour) Batch(times)

5 120×100×460 5.5 4

10 155×100×700 5.5 4

15 185×125×700 7.5 3

20 245×125×700 7.5 3

25 315×125×700 7.5 3

50 480×160×700 11.5 2

Block Ice

Block ice has a big advantage compared to other forms of ice in tropical countries. Storing, handling and transporting can all be simplified if the ice is in the form of large blocks. Simplifying the ice production process (storing, handling and transporting) is often essential in small-scale fisheries and in relatively remote areas. Moreover, under the same condition, block ice has the longest storage period.

Focusun indirect brine system block ice machine uses salt water as heat transfer medium. Temperature goes down to -5 Degrees Celsius through its heat exchange with refrigerant, then cold brine water continue to cool water in the ice cans. The ice produced could be delivered to ice storage or be crushed immediately as per customers' usage requirements. ice could be delivered to ice storage or be crushed immediately as per customers' usage requirements. As it is quite solid, difficult to melt, easy to store and transport, the block ice produced by brine method is very popular among coastal and tropical areas. Focusun continues to provide brine system block ice machine with improved technology to meet different ice requirements from customers.

Equipment features

Ti pipe is used as evaporative coil to improve the heat transfer effect, and its stainlessness, anti-corrosion can guarantee the long service time.

The stainless PE part between the brine and the fresh water is proper to mode and weld. And it works very well in a cold condition.

Energy saving: Power consumption is approx 70kw/Ton. Thus, less electricity is consumed.

The density of ice produced by brine system is 840~880kg/m3. Ice is therefore, very solid.

The meticulous design of ice thawing tank and ice dumping unit allows easy operation.

Modular and integrated design ensures that it is easy to ship, move and install on the spot.

Every brine refrigeration block ice machine can be customized to our clients' requirements.

Brine refrigeration block ice machine technical parameter

Direct System Block Ice Machine

Focusun direct system block ice machine adopts edge-leading refrigeration industry technology. After direct heat exchange between refrigerant and water, in 5 to 8 hours, water is frozen out into ice. By that time, PLC controls the machine automatically into ice doffing process. Direct system utilizes hot Freon to defrost ice; so the defrosting process is fast. Aluminum evaporator adopts special technique to make sure the ice conforms to food grade standards; in other words, the ice can be directly consumed. Besides saving labor work and electricity consumption, its unique modular design saves much floor area than traditional brine system block ice machine.

Equipment features of direct system block ice making machine

The evaporator adopts special aluminum alloy plate which is more durable and meets food hygiene requirements.

The density of ice produced by direct system is 820~860kg/m3.

Energy saving : Power consumption is approx 64kw/Ton. Thus, less electricity is consumed.

Ice thawing and ice doffing are fully automatic, therefore no manual work is needed. The efficiency of this process guarantees time-saving.

The ice is doffed by batch and the whole ice-doffing process only takes 25 minutes.

The whole batch of ice blocks can be moved by forklift. Quick and convenient.

Module design makes the ice maker easy to transport, move and install.

Every direct refrigeration block ice machine can be designed and produced according to customer specific requirements.

The direct refrigeration block ice maker machine can be installed in 20ft or 40ft brand new container with other relevant equipments.

Direct refrigeration block ice machine technical parameter

Containerized Block Ice Plant Focusun

Generally, working conditions are crucial for maintaining the stability and performance of an ice machine. Being containerized, the ice machine can work in a relatively isolated environment, where the ambient temperature can be controlled at 20℃-25℃.And all this facilitate the ice making process.

The whole container is specially treated and reinforced; this forms a perfect protection for the machine from physical damages, and outside dust.

Compared to the brine and direct refrigerating block ice machines, which requires to be fixed onto the plant ground, making transportation of the machine difficult, the containerized machine can be transported without problems.

Features of containerized block ice maker

Brand new ISO shipping container, in-house design decorated with lighting, drainage and exhaust system

Corrugated aluminum ground; slip resistant

The modular design helps anyone, regardless of experience, can operate the machine with ease.

The convenience in installation and transportation eliminates the extra costs and effort of building a new space to accommodate the machine

The entire system can keep an outstanding performance for years so that there is hardly any necessity for a trained engineer to be sent

Due to the special relationship Focusun hopes to establish, Focusun offers the customer exclusive rights to print their logos on the container without compromising the integrity of our product. However, the customer will need to apply for this exclusiveness.

Focusun provide Containerized Direct System Block Ice Machine and Containerized Brine System Block Ice Machine

Containerized direct system block ice maker

Containerized direct system block ice machine does not require any civil sheds and can be stationed very near to the fishing boats at Fishing Harbor /Centers, creating great convenience for the fishery industry. The need to obtain civil work planning permit may therefore be avoided.

Max capacity of direct system in 20'GP models: 6Ton/day

Max capacity of direct system in 40'HQ models: 18Ton/day

Models:

For many fisheries along the coastal areas, fishing tends to be seasonal, which means fishers may have to change from one location to another. In many cases, equipments would need to be moved along with the fishers. With their convenient mobility, this containerized brine system of block ice machine can be moved from coast to coast.

Containerized brine system block ice machine

Max capacity of brine system in 20'GP models: 5Ton/day

Max capacity of brine system in 40'HQ models: 12.5Ton/day
