    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power

    Ask Lasest Price
    Brand Name : FOCUSUN plate ice maker
    Supply Ability : 60 Set/Sets per Quarter Focusun plate ice making maker
    Price : $30,000.00/sets >=1 sets
    • Product Details
    • Company Profile

    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power

    Product Description

    FOCUSUN domestic 20t plate ice machine 15t plate ice machine plate ice machine


    FOCUSUN is the largest supplier of ice making machines in China, owns a factory of 36,000 square meters in producing different kinds of ice making machines such as block ice machine, tube ice machine, flake ice machine, plate ice machines, cold storage and packing machines. As for the Focusun plate ice machines which are available in capacities ranging from 1 to 60 tons per day. We classified all plate ice making equipment into 3 categories: small capacity, large capacity and containerized type.

    Features of Focusun plate ice :

    Plate Ice irregular transparent sheet ice, size around of 40×40mm to 80×80mm, which dimension is adjustable on request. Ice thickness is between 10~15mm, and it reaches to 20mm by Focusun tailor-made plate ice machine. The thickness of plate ice makes it suitable for long storage..


    High density, small surface area and good cool storage effect.

    Even cooling effect, good ventilation performance, and constant refrigerating temperature,

    suitable for refrigeration of aquatic products.


    Advantages:

    Focusun Plate Ice Machine Features
    Plate ice making machine use hot gas to make ice fall off fast and the whole process takes only 120 seconds;
    After plate ice falls off, the water of low temperature is used for ice-making to save energy consumption and increase the iceproduction volume;
    Add function of evacuating the remainder of the water in the cold water tank so that ice can be more clean and transparent;
    The use of stainless steel evaporator meet the health and safety requirements;
    Laser welding technology ensures minimum possibility of evaporator deform;
    Evaporator plate is free to increase or decrease so there are more styles of products;
    Time control can adjust the thickness of the plate ice;
    Integrated modular equipment facilitates installation and maintenance on spot;
    Touch screen, reserve function, Focusun mobile app remote video monitoring are available on request;

    If the ice storage is full,the plate ice machine will switch automatically into the water tank control mode to make sure the cold water inside the cold water tank always be at the set level. If the ice level inside the ice storage is again going down, the ice plate machine will switch again automatically ino the ice makin mode. During perids in which the plate ice plant is not producing, the plant automatically controls the water temperatue of the cold water using the recrcuation mode.
    Application fields: Plate ice is usually used for ice storage systems and is also applied to concrete mixing plants, chemical plants, mines, fresh vegetables, fishing and aquatic insulations.


    You could choose any models you like:

    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    Models
    Capacity
    Electricity consumption
    Dimension(mm)
    FIP-10
    1ton/day
    6.69kw.h
    1700×1200×1700
    FIP-20
    2ton/day
    9.92kw.h
    2200×1600×2000
    FIP-30
    3ton/day
    14.4kw.h
    2200×1500×2000
    Models
    Capacity
    Electricity consumption
    Dimension(mm)
    FIP-50
    5ton/day
    25.15kw.h
    2000×1800×2200
    FIP-100
    10tons/day
    39.07kw.h
    2200×1900×2200
    FIP-150
    15tons/day
    56.35kw.h
    2200×2100×2200
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    Models
    Capacity
    Electricity consumption
    Dimension(mm)
    FIP-200
    20ton/day
    84.00kw.h
    3800×2200×2450
    FIP-240
    24ton/day
    100.1kw.h
    4500×2200×2450
    FIP-320
    32ton/day
    124kw.h
    3200×2200×2450
    Models
    FIP-120
    12ton/day
    44.47kw.h
    2200×1900×2200
    FIP-400
    40ton/day
    154.7kw.h
    3800×2200×2450
    FIP-480
    48ton/day
    189.1kw.h
    3200×2200×2450
    Detailed Images
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    FIP-150WS
    Specifications For Plate Ice Machine
    Power Supply
    380V/50Hz/3P / 220V/60Hz/3P / 460V/60Hz/3P
    Cooling Way
    Water Cooling/Air Cooling/Evaporative Cooling
    Refrigerant
    R22/R404A
    Max. Ambient Temp.
    +45ºC
    Supply Water Temp.
    +25ºC
    Project pictures of plate ice machine
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power
    FOCUSUN Domestic 20t Plate Ice Machine 43000*2300*2500mm 72KW Installation Power

    Plate ice introduction: Plate ice is a kind of irregular sheet ice with about 40×40mm~80×80mm in size, and 10 mm~15mm in thickness. The thickness can be adjusted according to ice-making time with the maximum gauge being 20mm. Plate ice is a kind of thick and transparent ice which has good air permeability and a long shelf life. Small capacity from 1tons to 48tons day offered.


    In Plate Ice Machines, plates of ice form on both sides of stainless steel plates. The system is easy to maintain and clean. These plates of ice are hygienic, transparent and very hard, and can be stored for long periods of time. Thickness can be adjusted up to 20mm. Most of the parts are corrosion resistant and have a long service life. Our systems are energy efficient and operated via easy-to-use control panels. They’re self-contained systems, producing up to 48 tons of plate ice per day. Our Focusun plate ice machines are designed to work efficiently in different working conditions, some of the core applications of our Plate Ice Machines are: Fish processing Meat processing Poultry processing Supermarket Laboratories, pharmaceutical Chemical industries

    Welcome your inquiry, we will contact you today!
