Principle of Slurry Ice Machine:

Through the bottom of ice-crystal separating tank D, brine is pumped by circulating pump C into the ice maker. The pure water , contained in brine, can then either separate out ice crystal or turn into supercooled water that go back o the tank D again. Later, the supercooled water will separate out ice crystal in the ice-crystal separating tank D. Resulting from buoyancy, crystals set apart from water and distribute to the upper part of the tank D, while brine, locating below, would be pumped back to the ice maker A by ice making water circulation pump C. Repeatedly circulate.
——The ice scraper , mounted on the top of the tank D, would scrape out the ice crystals while in need. Crystals would be delivered to the ice storage tank or slurry ice reproducer, inside which the ice crystal and the water would mix and agitate, according to the pre-calculated recipe , to form slurry ice and pumped to each ice destination by slurry ice pump F.
——Salting tank B is required when using pure water or low concentration brine. Brine pump, equipped on the salting tank, will control over its operation via brine concentration sensor and controller to automatically maintain brine(in the tank D) concentration within setting range.
——When the rate of ice crystal is less demanded, ice maker A and reproducer F can be connected directly for periodic interval ice making. Ice maker will stop running when the crystal rate meeting requirement, while the slurry ice reproducer would work. The slurry ice produced would be pumped out by the slurry ice pump G. Circulation pump E, the same as circulation pump C, would circulate water.

Slurry ice advantages:

Compared with solid ice, slurry ice requires less energy, space and cost. Usually, for 6-14.5kg ice, 1 KWH electricity is required, while slurry ice machine can produce 21kg ice.

Slurry ice has the best cooling efficiency. 100% of its surface cooling area can be utilized. Compared with the mixture of flake ice and water, slurry ice demand less ice crystal.
Slurry ice is extremely suitable for pump delivery through hoses or pipes and easy to store and use.
Slurry ice can fully wrap the target products. Therefore, there is no air sink between the products and the slurry ice, maximize the contact and heat transmission surface. Absorb heat better, faster and more efficiently.
Slurry ice is soft without sharp edge. No damage to the surface of target products.

Slurry ice application fields:

Aquatic products processing
Meat processing
Fishery industry
Vegetable preservation
Supermarket or other commercial usage
Cold storage project
Temperature reduction project

Specification

Focusun produces a wide range of ice machines: tube ice machine, block ice machine, flake ice machine, cube ice machine, plate ice machine, and we also provide turnkey ice solutions, including water chiller, ice storage, ice packing machine, ice crusher and other equipments for commercial, industrial, institutional and other markets. Once you have the idea to build the ice factory, our engineers with years of experience are willing to recommend you the most suitable turnkey solution for you.
