    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Ask Lasest Price
    Brand Name : Focusun
    Supply Ability : 100 Set/Sets per Quarter
    Price : $42,188.00/units >=1 units
    • Product Details
    • Company Profile

    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Product Overview

    10T/Day Plate Ice Machine

    This machine can produce 10 tons of ice per day. Standard power supply for small capacity plate ice machine is 380V/3P/50Hz and it can be customized. With Bitzer semi-hermetic piston compressor it can be put into use when connecting water and electricity source.
    FEATURES AT A GLANCE

    Plate ice machine features:
    * By using water and heat Fluorine, the whole ice off process only needs 120 seconds.
    * Ice making time adopts time control, which can be set to adjust the thickness of the ice.
    * It conforms to the sanitary security requirements by adopting stainless steel SUS304, aluminum alloy plate chip evaporator.
    * Ice dump and water drainage function makes ice more clean and transparent.
    * It is convenient to install and maintain because of its modular equipment.

    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm
    Plate ice introduction:
    Plate ice is a kind of irregular sheet ice with about 40×40mm~80×80mm in size, and 10 mm~15mm in
    thickness. The thickness can be adjusted according to ice-making time with the maximum gauge being 25mm.
    Plate ice is a kind of thick and transparent ice which has good air permeability and a long shelf life.

    Application fields:
    Plate ice is usually used for ice storage systems and is also applied to concrete mixing plants, chemical
    plants, mines, fresh vegetables, fishing and aquatic insulations.

    Ice making process introduction:
    When the refrigeration system begins operating normally, the water in the tank below is transported from the cold water tank to
    the cold water sprinkler by the cold water pump. It is then evenly sprinkled on the surface of the evaporator. Through the cycle
    working of the refrigerant, some water is created into plate ice, while the water which does not become ice returns to the cold
    water tank below and waits for the next water cycle. After a period of time the water cycle and refrigeration stops and the water
    and overheating refrigerants gas begin a heat exchange with the plate ice at the same time. The plate ice then loses adhesive force and the ice drops into the ice crushing gadget due to gravity. After the ice is off the water temperature becomes low and it returns into the water sink waiting the next cycle.

    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm
    PRODUCT SPECIFICATIONS
    No
    Item
    Data
    1
    Power supply
    380V/3P/50Hz
    2
    Refrigerant
    R22 or R404A
    3
    Capacity
    10000Kg/day
    4
    Cooling way
    Water cooling
    5
    Total running power
    39.07kw
    6
    Installment power
    48kw
    7
    Size of machine unit
    1600×1200×1800mm
    8
    Size of evaporator
    2200×1700×2200mm
    9
    Size of cooling tower
    Ф2000×2410
    SALES AND SERVICE NETWORK
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm
    SIMILAR PRODUCTS
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Focusun 10T/Day Tube Ice Machine

    Daily Capacity: 10T/24 H
    Refrigerant: R22/R404A
    Installed Power: 45kw
    Power Supply: 50Hz,380V, 3P
    Condenser: Air cooling/Water cooling/Evaporative cooling
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Focusun 15T/Day Flake Ice Machine

    Daily Capacity: 15T/24 H
    Refrigerant: R22/R404A
    Installed Power: 60kw
    Power Supply: 50Hz,380V, 3P
    Condenser: Evaporative cooling
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Focusun 30T/Day Block Ice Machine

    Daily Capacity: 30T/24 H
    Refrigerant: R22/R404A
    Installed Power: 150kw
    Power Supply: 50Hz,380V, 3P
    Condenser: Evaporative cooling
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Focusun Snowmaking Machine

    Daily Capacity: 4500KG/24 H
    Refrigerant: R404A
    Adjusting snowflake size: Variable Frequency Regulation
    Power Supply: 50Hz,380V, 3P
    Condenser: Air cooling/Water cooling
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Focusun 900KG/Day Cube Ice Machine

    Daily Capacity: 900kg/24 H
    Capacity of Ice Bin: 315kg
    Refrigerant: R22/R404A
    Power Supply: 50Hz,380V, 3P
    Condenser: Air cooling/Water cooling
    Focusun 10T/Day High Productivity Plate Ice Machine for Bitzer Compressor 1600*1200*1800mm

    Focusun 10T/Day Cube Ice Machine

    Daily Capacity: 10 T/24 H
    Refrigerant: R22/R404A
    Condenser: Air cooling/Water cooling/Evaporative cooling
