    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial

    Ask Lasest Price
    Model Number : FIP-200WS
    Supply Ability : 100 Set/Sets per Quarter
    Price : $18,000.00/units 1-1 units
    • Product Details
    • Company Profile

    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial

    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Product Overview

    Big plate ice making plant for industrial use

    NPlate Ice featured with irregular transparent sheet ice, size around 40×40mm to 80×80mm, but dimension is adjustable on request. Ice thickness is between 10~15mm, and it reaches to 25mm by FOCUSUN tailor-made plate ice machine. The thickness of plate ice makes it suitable for long storage.
    FEATURES AT A GLANCE
    The body is made of anti-corosive painted steel, all parts contact with water is SUS304A
    Semi hermetic compressor, brand Bitzer
    R404a, R448A, R449A, R507A refrigerant o
    Widely used seafood storage and fish processing plants.Ice is not easy to melt with a long storage period

    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    DANFOSS VALES
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    LIANGCHI WATER COOLING TOWER
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    STAINLESS STEEL SHEETS

    Plate ice machine application

    FOCUSUN plate ice machine can be widely used for most of ice application:
    (1) The plate ice machine can be used for beverage industry for cooling soft drinks
    (2) The ice can be used in concrete Mixing
    (3) The plate ice machine can be used in chemical plant
    (4) The plate ice machine is applied to mine cooling
    (5) The plate ice is suitable for supermarket retain freshness cooling
    (6) The plate ice is widely used seafood storage and fish processing plants
    (7) The ice can be used in fruit & vegetables preliminary process
    (8) The plate ice is suitable for meat processing

    PRODUCT SPECIFICATIONS
    Model
    Daily capacity
    Ice storage capacity
    Cooling mode
    Refrigerant
    FIP-10AS
    1TON/DAY
    1000KG
    AIR COOLING
    R404A/R507A
    FIP-20AS
    2TON/DAY
    2000KG
    AIR COOLING
    R404A/R507A
    FIP-30AS
    3TON/DAY
    3000KG
    AIR COOLING
    R404A/R507A
    FIP-50AS
    5TON/DAY
    5000KG
    WATER COOLING
    R404A/R507A
    FIP-100WS
    10TON/DAY
    10,000KG
    WATER COOLING
    R404A/R507A
    FIP-200WS
    20TON/DAY
    20,000KG
    WATER COOLING
    R404A/R507A
    FIP-250WS
    25TON/DAY
    25,000KG
    WATER COOLING
    R404A/R507A
    FIP-300WS
    30TON/DAY
    30,000KG
    WATER COOLING
    R404A/R507A
    FIP-480WS
    48TON/DAY
    40,000KG
    WATER COOLING
    R404A/R507A
    Focusun offers you the best of tailored Plate Ice Making Systems. Not only do we supply the ice machines, but also offer you technological consultancy. Focusun manufactures the ice machines that reach high sanitary standards, so every evaporator of our Plate Ice Plant adopts stainless steel SUS304 and aluminum alloy plate chip.

    Focusun Plate Ice Makers are divideded into small capacity and large capacity machines, ranging from 1Ton/Day to 48Tons/Day. Small capacity is our indoor standardized Plate Ice Plant which enjoys a reputation of high efficiency and low energy consumption.

    The modular design of the Plate Ice Maker simplifies the spot maintenance and the replacement of spare parts. Regarding the large capacity Plate Ice Plant, it is always used for our Dynamic Ice Storage System to reduce the valley-to-peak ratio of grid load. Dynamic Ice Storage is a cold ice storage air-conditioner which consumes low energy and operates under low cost.
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Certifications
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    FAQ
    Q1. What is your terms of packing?
    A: Generally, we pack our goods in platict films or cartons, normally a FCL shipping.

    Q2. What is your terms of payment?
    A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay thebalance.You're welcome to see the test of the machines for days.

    Q3. What is your terms of delivery?
    A: EXW, FOB, CFR, CIF.

    Q4. How about your delivery time?
    A: Generally, it will take 45 to 60 working days after receiving your advance payment. The specific delivery time depends on
    theitems and the quantity of your order.
    Q5. Can you produce according to the samples?
    A: No, all the machines are customized according to power supply ice size in difference. We don't provide sample.

    Q6. What is your aim?
    A: And we would be happy that our customers using our brand Focusun across our world. We aim to give customer best products withreasonable price.

    Q7. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery.

    Q8: How do you make our business long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they comefrom.
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Stainless Steel/Galvanized Steel Material 20 000kg Plate Ice Making Plant for Industrial
    Welcome to contact FOCUSUN headquarter to get more videos, price.
    We have a few questions for you to answer in order to give you the right price according to your requirements. We are apprecaited if you could send enquiry with these replies, as we don't need to ask you again.
    1. What is your main business area?
    2. What is your preferred type of ice machine for business?
    3. How many tons of ice capacity is needed in 24hours?
    Don't worry about the power supply, because Focusun provide several options such as 380V/3P/50HZ, 220V/3P/60HZ, 440V/3P/60HZ, 380V/3P/60HZ.
