    50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant

    Ask Lasest Price
    Brand Name : FOCUSUN
    Certification : CE
    Supply Ability : 35 Set/Sets per Month
    Price : $50,000.00 - $100,000.00/units
    • Product Details
    • Company Profile

    50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant


    General Introduction about Focusun :


    Focusun is the refrigeration equipment manufacturer leading the peer industry. We mainly produce flake ice machine, tube ice machine, block ice machine, plate ice machine, cube ice machine, water cooling equipment, concrete cooling system, dynamic ice storage system, and all kinds of low temperature ice storage room.


    Quick Introduction about the block ice plant, Model: FIB-500S


    Type:Brine system block ice plant
    Power Supply:220v/415V/50Hz/3P
    Model No.:FIB-500S
    Capacity:50000KG/DAY
    Cooling way:Water-cooling
    Compressor:Bitzer
    Refrigerant:R22/R404A
    Dimension:

    See layout design

    Brief introductionThe production of block ice is a batch operation and, once emptied, the cans are refilled with water and replaced in the brine tank for a further freezing period. Whatever the capacity of the ice-maker for block ice production, a continuous labour force is required to manage all operations, particularly ice harvesting and handling. All process could be completed within the container.

    Note: We have block ice plants of small, medium, large capacity, which ranges from 1t to 100t or more. All the specifications


    can be personalized according to your requirments.


    If you need more technical parameters, you http://www.block-ice-plant.com/
    may visit our website to get more details about our ice machines :


    http://www.block-ice-plant.com/



    The main advantages of Focusun block ice:


    Comparing to other forms of ice, block ice is specially designed for tropical and hot areas, for middle east, African, etc. Stroage, handling and transport can all be simplified especially for remote areas transportation. Moreove, under the same condition, block ice has the longest storage period.


    Brine refrigeration block ice machine technical parameter

    ModelCapacityRefrigerantElectricity consumptionInstallment powerOperating weightDimension
    --Ton/D--KwKwKgmm
    FIB-50B5R22/R404A21.1425UnitL1400×W1000×H1250
    EvaporatorL4800×W1000×H2250
    Cooling tower1380×H2170
    FIB-100B10R22/R404A40.6950Unit:1680L1800×W1000×H1450
    Evaporator:2860×2L4800×W1000×H2250
    Cooling tower:6702000×H2410
    FIB-150B15R22/R404A60.6075Unit:2160L2000×W1200×H1600
    Evaporator:2860×3L4800×W1000×H2250
    Cooling tower:11202175×H2565
    FIB-200B20R22/R404A88.50105Unit:2896L2400×W1600×H1800
    Evaporator:2860×4L4800×W1000×H2250
    Cooling tower:13002650×H2645
    FIB-250B25R22/R404A98.80120Unit:3260L3200×W1800×H2200
    Evaporator:2860×5L4800×W1000×H2250
    Cooling tower:16303050×H2780
    FIB-300B30R22/R404A120.30150Unit:3500L3000×W2000×H2200
    Evaporator:2860×6L4800×W1000×H2250
    Cooling tower:27303300×H2785
    Standard condition: Dry ball temperature is 33 °C and water inlet temperature is 20°C.


    50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant


    50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant


    50 Tons Per Day Ice Block Making Machine with Compressor and R22 or R404A Refrigerant


    Dear friends, don't hesitate to send your inguiry if you are interested!

    We would be very glad to be on service for you, as the most professional ice machine manufacturer with the biggest factory base in China, we are pleased to attach our best offer. We are definitely to contact you within 3 days after getting your inquiry.
